I. Kev npaj ua ntej calibration
Cov cuab yeej hauv qab no suav nrog hauv daim ntawv teev cov cuab yeej: Qib 0 feeler gauge, standard gauge block, digital multimeter, host computer calibration software, and shielded electronic tools.
Yam yuavtsum tau kawm uantej: Xyuas kom meej tias lub sensor yog powered rau thiab tau preheated rau 15 feeb. Cia tus kub khiav mus rau qhov chaw sov (25 degree). Tshawb xyuas cov xaim rau kev ruaj ntseg thiab kev sib txuas lus txuas rau kev ua haujlwm.
II. Kev txheeb xyuas ntawm cov teeb liab txuas
Xyuas kom tseeb tias lub sensor tiag tiag - cov ntaub ntawv hloov pauv lub sijhawm tuaj yeem tshwm sim synchronously thiab ib txwm nyob ntawm lub khoos phis tawj tswj hwm, tsis muaj kev sib txuas lus cuam tshuam lossis cov ntaub ntawv tsis raug.
Txheeb xyuas qhov 4 ~ 20mA analogue tso zis teeb liab siv lub digital multimeter. Paub meej tias 0mm hloov chaw sib raug rau 4mA, tag nrho - nplai hloov pauv sib haum mus rau 20mA, thiab lub teeb liab sib txawv tsawg dua lossis sib npaug rau 0.1mA.
III. Retest ntawm tag nrho stroke raug
Sau cov ntaub ntawv hloov chaw los ntawm qhov taw tes, kom ntseeg tau tias tag nrho cov hlab ntsha tawg yog cov kab thiab tsis muaj kev hloov pauv sai lossis cov teeb liab dhia los ntawm jamming, los ntawm manually thawb lub phaj kub khiav hauv ob qho tib si rau pem hauv ntej thiab rov qab cov lus qhia nyob rau hauv peb tag nrho strokes.
Paub meej tias qhov ntsuas qhov hloov pauv ntawm peb lub ntsiab lus random yog nyob rau hauv qhov sib txawv ntawm 0.1mm los ntawm tus nqi tso tawm sensor thiab tias qhov yuam kev rov ua dua yog tsawg dua 0.05mm los ntawm kev siv lub ntsuas ntsuas.
IV. Thermal Stability Debugging
Saib xyuas cov ntaub ntawv hloov chaw ntawm lub sensor tso tawm thoob plaws lub sijhawm ntawm ib teev tom qab qhov kub khiav tau pib rau nws qhov ntsuas kub ua haujlwm.
Sib piv qhov tiag -time displacement qhov tseem ceeb nrog theoretically xam thermal expansion qhov tseem ceeb los xyuas kom meej tias tsis muaj tus lej hloov pauv los ntawm qhov kub thiab txias thiab qhov sib txawv tsawg dua 0.2 hli.
V. Debugging lub tswb Interlock muaj nuj nqi
Teem qhov hloov chaw hla - txwv lub tswb ceeb toom rau 90% ntawm tus kub khiav qhov kev nyab xeeb nthuav dav tshem tawm thiab manually simulate qhov xwm txheej hloov chaw uas dhau qhov kev zam.
Paub meej tias lub kaw lus cia li ua tiav cov cua sov thiab kev ua kom qeeb thiab tso tawm cov lus ceeb toom cuam tshuam rau qhov kub khiav kub tswj qhov system hauv 1 thib ob, ua rau lub tswb nrov uas twb muaj lawm thiab pom.
VI. Archiving thiab Kev Tshawb Fawb Kawg
Khiav tus kub khiav tsis tu ncua rau 2 teev tom qab nws nkag mus rau qhov qub ntau lawm. Xyuas kom meej tias cov ntaub ntawv soj ntsuam sensor nyob ruaj khov thoob plaws, tsis muaj lub tswb tsis raug lossis tsis muaj lub tswb.
Tag nrho cov txheej txheem debugging yog ua tiav los ntawm kev txuag tag nrho cov kev debugging tsis, tsim thiab khaws cov ntaub ntawv debugging.
Cov khoom tsim tawm hauv tsev qis -tus nqi Hall effect displacement sensor koj xaiv tau ua tiav nrog cov txheej txheem kev debugging. Lub sensor tuaj yeem pib sai sai thiab ua haujlwm los ntawm cov kws saib xyuas kev noj qab haus huv zoo ib yam los lav tias nws tuaj yeem saib xyuas cov thermal expansion hloov pauv lub xeev ntawm cov kub khiav rau lub sijhawm ntev.
